Product Details:
|
| Material: | Nickel Alloy | Application: | Spring |
|---|
Similar high temperature resistance to INCONEL 600/601 with improved strength, while offering comparable corrosion resistance to INCONEL 625.
Diameter: 0.1 - 40mm
Shape: round, square, flat, special shaped
Similar high temperature resistance to INCONEL 600/601 with improved strength, while offering comparable corrosion resistance to INCONEL 625.
Aerospace Components
Land Based Gas Turbines
Power Generation
Acid Processing
Petrochemical Processing
Springs
UNS N06617
W.Nr. 2.4663
NiCr22Co12Mo9
ASTM B166
ASTM B168
AMS 5887
AMS 5889
ISO 9724
ISO 6208
DIN EN 17753
| Element | Min % | Max % |
| Ni | 44.5 | – |
| Cr | 20 | 24 |
| Co | 10 | 15 |
| Mo | 8 | 10 |
| Al | 0.8 | 1.5 |
| C | 0.05 | 0.15 |
| Fe | – | 3 |
| Mn | – | 1 |
| Si | – | 1 |
| S | – | 0.015 |
| Ti | – | 0.6 |
| Cu | – | 0.5 |
| B | – | 0.006 |
| Density | Melting Point | Coefficient of Expansion | Modulus of Rigidity | Modulus of Elasticity |
| 8.36g/cm³ | 1330 – 1380 °C | 11.6 μm/m °C (20 – 100 °C) | 81 kN/mm² | 212.0 kN/mm² |
| 0.302 lb/in³ | 2430 – 2510 °F | 7.0 x 10-6 in/in °F (70 – 212 °F) | 11.8 ksi | 30700 ksi |
| Approx. tensile strength | <1000 N/mm² | <145 ksi |
| Approx. operating temperature depending on load and environment | Up to 1100 °C | Up to 2012 °F |
| Approx. tensile strength | 1300 – 1600 N/mm² | 190 – 230 ksi |
