SUS631J1 Stainless Spring Steel Wire

China Hunan Fushun Metal Co., Ltd. certification
China Hunan Fushun Metal Co., Ltd. certification
I'm Online Chat Now

SUS631J1 Stainless Spring Steel Wire

SUS631J1 Stainless Spring Steel Wire
SUS631J1 Stainless Spring Steel Wire SUS631J1 Stainless Spring Steel Wire

Large Image :  SUS631J1 Stainless Spring Steel Wire

Product Details:
Place of Origin: China
Brand Name: Fushun
Certification: ISO9001:2008
Model Number: SUS631J1
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: nylon/pallet/case
Delivery Time: 15-30 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 40,000tons/year

SUS631J1 Stainless Spring Steel Wire

Grade: SUS631J1 Feature: Stainless
Form: Wires Standard: JIS G4314 SUS631J1
High Light:

ISO9001 Stainless Spring Steel Wire


Mechanical Stainless Spring Steel Wire



JIS G4314 SUS631J1 Stainless Spring Steel Wire for Mechanical Springs

Grade : SUS631J1 Classification: Corrosion-resisting / heat-resisting steel Precipitation hardening steel Standards: JIS G 4318 : Cold finished stainless steel bars JIS G 4308 : Stainless steel wire rods JIS G 4314 : Stainless steel wires for springs


Supplying Size:


Our Advantage
1. Stable linearity, good formability. Uniform and beautiful surface condition.
2. High plasticity and good fatigue resistance. And we provide Self-Inspection Reports and Raw-Material Test Certificates.
3. Professional anti-rust protective packaging. On time delivery, competitive price.
4. Large stock available, no MOQ requirement.


Equivalent Materials
DIN 1.4568DIN X 7 CrNiAl 17 7AFNOR Z9CNA17-07AISI 631AISI 631 (17-7PH)SAE 631SAE 631 (17-7PH)JIS SUS631JIS SUS631-CSPEN X7CrNiAl17-7EN 1.4568UNS S17700


SUS631J1 Stainless Steel Wire Chemical composition

C Si Max Mn max P max. S max. Cr Nl Al
0.09 MAX 1.00 MAX 1.00 MAX 0.040 MAX 0.030 MAX 16,00- 18,00 7.00 - 8.50 0.75-1.50


SUS631J1 Stainless Steel Wire Form of delivery

The wire shall be supplied in coils, on spools, on spoolless cores or carriers. Several coils may be assembled on a carrier. Unless otherwise specified the form of delivery shall be at the manufacturer's discretion. He shall however inform the purchaser about the form of delivery.


SUS631J1 Stainless Steel Wire Surface finish

The wire may be coated or not. The specific coating and finish for stainless steel spring wire shall be agreed upon at the time of enquiry and order- e.g. uncoated, polished finish, nickel coated.


SUS631J1 Stainless Steel Wire Information to be supplied by the purchaser

The purchaser shall clearly state in his enquiry or order the product and following information:

a) the desired quantity;

b) the number of this European Standard: JIS G4314;

c) the steel grade and for grade 1.4310 also the tensile strength level;d) the nominal wire diameter;

e) the surface finish

f) the form of delivery

g) the type of inspection document to be supplied;

h) any particular agreement made.


SUS631J1 Stainless Steel Wire Manufacturing process

Unless otherwise agreed in the order, the manufacturing process used in the making of the stainless steel wire is left to the discretion of the manufacturer. The starting condition (+AT:solution annealed)of the wire (rod) is specified in EN 10088-3.


stainless steels are usually used in the cold drawn condition in the form of wire of circular cross-section up to 10,00 mm in diameter, for the production of springs and spring parts that are exposed to corrosive effects and sometimes to slightly increased temperatures.

1.4571,1.4539,1.4028 are also used for springs,although to much lesser extent. In these cases the mechanical properties(tensile strength, etc.)should be agreed between purchaser and supplier. Similarly, diameters between 10,00 mm and 15,00 mm may be ordered against this standard; in this case the parties should agree upon the required mechanical characteristics.
