Product Details:
|
Grade: | SUS420J2 | Feature: | Stainless Steel |
---|---|---|---|
Shape: | Steel Strip | Surface Condition: | Bright Surface (2H), Or A Rough, Matt Surface |
Stainless Grade: | SUS420J2-CSP | From: | Stainless Strips Coils |
Standard: | JIS G4313 SUS420J2 | ||
Highlight: | 30mm Stainless Steel Sheet Coil,JIS G4313 Stainless Steel Sheet Coil,SUS420J2-CSP |
Grade : SUS420J2 Classification: Corrosion-resisting / heat-resisting steel Martensitic steel
Standards:
JIS G 4304 : Hot-rolled stainless steel plate, sheet and strip
JIS G 4305 : Cold-rolled stainless steel plate, sheet and strip
Dimensions and tolerances
Thickness: 0.01 to 5 mm; Tolerances: +/- 0.008 to 0.11 mm
Width: 5 to 1219 mm; Tolerances: +/- 0.15 to 0.60
*accept nonstandard size, please contact with our sales.
Our Advantage
1. Precise thickness, uniform hardness. Bright surface, smooth edge.
2. High flatness of board surface, high performance after multiple bending.
3. No cracking after stamping, and the quality is stable. And we provide Self-Inspection Reports and Raw-Material Test Certificates.
4. Professional anti-rust protective packaging. On time delivery, competitive price.
5. Large stock available, no MOQ requirement
SUS420J2-CSP Stainless Steel Strip Chemical compositions
Symbol of grade | C | Si | Mn | P | S | Ni | Cr | Cu | Others |
SUS420J2-CSP | 0.26 to 0.40 | 1.00 max. | 1.00 max. | 0.040 max. | 0.030 max. | / | 12.00 to 14.00 | / | / |
SUS420J2-CSP Stainless Steel Strip Mechanical properties
Symbol of grade | Symbol of tem-per | Cold rolling or annealing, or aging treatment after solution treatment | ||
Proof stress N/mm2 | Tensile strength N/mm2 | Elongation % | ||
SUS420J2-CSP | O | 225 min. | 540 to 740 | 18 min. |
SUS420J2-CSP Stainless Steel Strip Appearance
The surface of strip shall be well finished and free from defects detrimental to practical use; however, those supplied in coiled-state may inevitably contain some abnormal portions since processing of strip generally does not allow opportunity for defects
removal.
SUS420J2-CSP Stainless Steel Strip Marking
The strips having been passed the inspection shall be legibly marked on each bundle (package) with the following items. A part of items may be omitted upon the agreement between the purchaser and the manufacturer.
a) Symbol of grade
b) Symbol of temper
c) Dimensions
d) Symbol of tolerance (that according to tolerance symbol of thickness ET or ST shall be marked)
e) Serial number or inspection number
f) Manufacturer's name or its abbreviation
the stainless steel strip mainly used for flat springs and spiral springs. Further, this Standard applies to the cut-to-length which is cut from the strip.
SUS420J2-CSP Stainless Steel Strip Manufacturing method
The strips shall be manufactured by cold rolling. After cold rolling, SUS420J2-CSP-0 shall be subjected to the annealing, and SUS631-CSP-0 shall be subjected to the solution treatment.
SUS420J2-CSP Stainless Steel Strip Inspection and testing
a suitable frequency of verification of the dimensions of the products;
an adequate intensity of visual examination of the surface quality of the products;
an appropriate frequency and type of test to ensure that the correct grade of steel is used.
Extent of testing
Tensile and bending tests
Tolerances on shape
